Description

We are often asked, "Which wheelset do you ride on your trail bike?" We admit, the answer should be a pretty straightforward. But when you have rims and hubs and time at your disposal, it can lead you to places that are different than you might expect.

Enter Frysauce.

Like mixing ketchup and mayonnaise to create the perfect french-fry accoutrement, the perfect wheelset may require combining seemingly disparate things. In this case, it's our venerable 30|SL and 30|HD, built into the respective front and rear wheels to provide the perfect combination of compliance and stiffness for your trail riding pleasure. It's the wheelset we ride most, and starting today, you can too!

See Full Specs

01 Rim Profile

02 SL Front | HD Rear

03 Asymmetrical Design

01Rim Profile02SL Front | HD Rear03Asymmetrical Design

Rim Profile

Reserve's new redesigned rim bed eases tubeless installation, with a shaped rim bed utilizing offset spoke holes that allows the tire to easily push past the bead bump to seat tubeless tires.

SL Front | HD Rear

By coming our 30|SL and 30|HD in a front and rear wheelset package, we are giving you the inside line to the trail bike wheelset. Stiff and compliant in equal measure, the wheelset delivers just what you need, where you need it most.

Asymmetrical Design

Asymmetrical rims, like those on the 30|SL and 30|HD, build stiffer, stronger and more reliable wheels by improving the bracing angles and equalizing the spoke tensions between the drive and non-drive side spokes.

Details

Wheel Size

Designed For Trail, All Mountain, Enduro
Hub Spacing Boost: 15x110 F - 12x148 R
Spoke Count 28
Wheelset Weight 29" 1752g - MX 1732g
Rim Weight 449g (30SL) - 515g (30HD 29) - 497 (30HD 27.5)
Inner Width 30mm
External Width 37mm
Rim Depth 19mm (30SL), 20mm (30HD)
Asymmetric Offset 3mm
ERD 29" - 599 (29 30SL) - 598 (29 30HD) - 559 (27.5 30HD)
Recommended Tire Dimensions 2.2" to 2.6"

Not Sure Which Wheelset is Right For You? Watch This Short Video:

FAQ

What's with the raised square-shaped area around the spokes?

That's material right where you need it. With information from testing in our carbon lab in hand, we set about determining how to build the strongest rim possible, and part of the result is the square-shaped reinforcements you can see around the spoke holes.

Where can I find more tech spec information?

Click here for all our technical documents.

Didn't see your question?

Click here for a full list of frequently asked questions.
